Insulation: up to 2GΩ at 250V, 500V and 1,000V DC
Voltage indication before insulation measurement: 0 to 600V AC/DC (blocking if U>25V)
Continuity: -20Ω to +20Ω (audible beep and compensation of leads)
Resistance: 0 to 400kΩ
Chauvin Arnoux C.A 6525, Insulation & Continuity Tester, 1000V, 2000MΩ, CAT III 600 V
R10,913.00 _Incl Vat
The range of megohmmeter models C.A 6521, C.A 6523 and C.A 6525 make measurement both straightforward and convenient.
Digital LCD with simulated analogue arc bargraph200mA continuity test capabilityContinuity buzzerLead resistance compensation (Not CA6521)Auto power down to save batteriesBattery life indicationProgrammable thresholds with buzzer alarmTimer measurements over long periods (CA6525 only)IP54 ingress protection
Specifications
| Attribute | Value |
|---|---|
| Tester Type | Insulation & Continuity Tester |
| Minimum Test Voltage | 250V |
| Maximum Test Voltage | 1000V |
| Maximum Insulation Resistance Measurement | 2000MΩ |
| Display Type | Analogue |
| Test Current | 200mA |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +55°C |
| Power Source | Battery |
| Safety Category Level | CAT III |
| Safety Category Voltage | 600V |
| Safety Category | CAT III 600 V |
| Width | 108mm |
| Battery Type | AA |
| Length | 211mm |
| Dimensions | 211 x 108 x 60mm |
| Weight | 835g |
| Model Number p | C.A 6525 |
| Height | 60mm |
